Accurate spectral measurements of solar radiation – why we need improved understanding in the near-infrared

Weather and climate processes are fundamentally driven by energy flows within the Earth-atmosphere system. Incoming solar radiation is absorbed and scattered by gases and aerosols within the atmosphere and absorbed and re-emitted by the Earth’s surface. We therefore need to know how much energy is absorbed by the atmosphere and the height at which this radiation is absorbed.

Currently, we know to reasonable accuracy and precision where most of this energy is accounted for (what we call the global energy budget).

Slide1
Fig. 1 (Stephens et al. 2012, Nature Geoscience), values in W m-2

Some of the values on the above figure (Figure 1) are highlighted in purple – this indicates that the relative uncertainty (i.e. the range in which this value might plausibly be) on these values is rather high. Reducing the uncertainty on these values is important: this will improve the accuracy of models we use to determine weather and climate. This is achieved by advances in modelling techniques, or in the case of my PhD improvements in available measurements of processes in the atmosphere.

My PhD work focuses on the components circled above, the short-wave atmospheric absorption (i.e. solar energy which is absorbed by the atmosphere as it travels from the Sun toward the surface), and on the incoming solar radiation. The latter of these has a small uncertainty, but this does not quite tell the whole story. The spectral distribution (i.e. at what wavelengths this radiation is emitted) of this energy is also extremely important, since the atmosphere is more transparent at some wavelengths than others.

Slide2
Fig. 2: Model run of water vapour absorption in the near-infrared for a mid-latitude Summer atmosphere. Everywhere (roughly) above the blue line is considered completely opaque, with varying degrees of transparency below this.

My work focuses on the “near-infrared” spectral region, between about 1-5 μm (or 2000-10000 cm-1) . This region, as can be seen in the above figure, has a “band-window” structure, where parts of the spectrum are completely opaque to radiation, but other parts are almost entirely transparent. Solar radiation with the same wavelength as these band regions where the absorption is strongest will therefore be deposited in the upper atmosphere, while radiation within the windows will be absorbed throughout the atmosphere and by the surface. This structure is almost entirely due to absorption by water vapour.

It is therefore extremely important to characterise the absorption in these windows as much as possible, since any additional absorption will affect where in the atmosphere solar energy is absorbed (unlike additional absorption in the band regions which will barely affect where in the atmosphere this absorption takes place).

Figure 2 also shows the water vapour continuum; a component of absorption which is not currently fully understood. This absorption is a phenomenon not fully accounted for by the theory of water vapour absorption; currently we model it using the MT_CKD model (named such after its creators). The strength of this absorption may be significantly stronger than this model however; laboratory measurements show differences of up to a factor of 100 in the strength at about 1.6 μm!

It is believed (e.g. Radel et al. (2013)) that an increased continuum could contribute about 3 W m-2 to the overall shortwave atmospheric absorption; a significant portion of the 10 W m-2 uncertainty in Figure 1.

My work attempts to resolve this using direct measurements of solar radiation in this 2000-10000 cm-1 region using a Fourier Transform spectrometer, made by the National Physical Laboratory at a site at Camborne, Cornwall, UK. There are a number of challenges making such measurements in the atmosphere; the instrument needs to be properly calibrated, and the conditions in the atmosphere (specifically temperature, pressure, humidity and aerosols) need to be well characterised. This is done using contemporaneous measurements using a radiosonde (to measure the atmospheric profile) and a sunphotometer (to measure aerosol optical depth). These radiosonde measurements are then put into a line-by-line radiation code to calculate the atmospheric optical depth, and these two contributions are subtracted from the total optical depth to get the continuum optical depth.

To derive the continuum it is necessary to know what the incoming solar radiation is. It turns out this is also a significant uncertainty in the literature in the 2000-10000 cm-1 region. While the total incoming solar irradiance is well-known, the distribution of that energy with the electromagnetic spectrum is not so well known. In the spectral region I’m looking at, that uncertainty is about ~10% between different sets of observations.

Since we have direct measurements of the Sun with absolute calibration, we can determine this from our own measurements, and found that the irradiance in this region may be significantly lower (16 W m-2 integrated over the whole spectral region) than expected, which must be made up by contributions elsewhere in the spectrum to account for the small uncertainty in the incoming solar radiation from Figure 1.

Slide3
Figure 3: Solar spectral irradiance in the 4000-10000 cm-1 region from CAVIAR2 (my work) compared with different sets of observations from other groups (ATLAS3 and Solar2). My work agreed significantly better with the Solar2 work in the 4000-7000 cm-1 region, with good agreement with both in the 7000-10000 cm-1 region. (From Elsey et al. [2017])
Following this, more work was put in to deriving the continuum. This is a more difficult task than simply measuring the incoming solar radiation, since we need to know the different components of the absorption in detail rather than filtering out the effect of the entire atmosphere. Figure 4 shows our best estimate of the continuum, showing a much stronger absorption than MT_CKD. There are large uncertainties however, due to the difficulty in attributing each component of the absorption. Thus, it cannot be ruled out entirely that MT_CKD is representative of the continuum, merely that is likely to be too weak.

Slide4
Fig. 4: Derived continuum absorption from my observations vs MT_CKD. Dark blue regions indicate k = 1 (67% confidence interval) uncertainties, cyan indicates k = 2 (95% confidence interval) uncertainties.

In the last part of my PhD, I hope to look at what effect these two results might have on the Earth’s energy budget, and look at how much of this 10 W m-2 uncertainty might be accounted for by them. This ties in well with a new project (ASPIC, Advanced Spectroscopy for improved characterisation of the near-Infrared water vapour Continuum) starting up at Reading and the Rutherford Appleton Laboratory in June, which hopes to look at new laboratory measurements of the continuum and assess the effect a strengthened continuum may have on radiation models.



The 2017 SCENARIO Conference: Frontiers in Natural Environment Research

Every year students from the SCENARIO (Science of the Environment, Natural and Anthropogenic Processes, Impacts and Opportunities) Doctoral Training Partnership organise an annual conference. Those invited include SCENARIO students, NERC employees and industrial partners. This year, after last year’s successful collaboration with the University of Oklahoma, it was decided that we would run the conference (Frontiers in Natural Environment Research) with the Science and Solutions for a Changing Planet (SSCP) and London NERC DTPs, led by a variety of universities and institutions in London.

A similar conference was organised last year (Perspectives on Environmental Change) between SSCP and the London NERC DTP, which was a rousing success. This year, with the addition of Reading and Surrey, we had almost 200 delegates attending with a healthy proportion of supervisors and industry partners, with over 40 oral presentations and 40 posters from students at the various institutions. The conference was held in the Physics building at Imperial College, a literal stone’s throw away from the Royal Albert Hall.

Organising the conference was a daunting task; there was a lot of work involved between the nine PhD students on the committee! One of the challenges, (but also one of the most exciting parts of the conference), was the sheer variety of research being presented. Many of the attendees were from the Met department, but there were also students from Chemistry and Geography from SCENARIO, and students from the London institutions doing topics as varied as sociology, ecology, biology, materials science and plate tectonics. This made for a really interesting conference since there was so much on offer from such a wide range of fields, but made our lives quite difficult when trying to organise keynote speakers and sort abstracts!

IMG_8983

As well as the student presentations we also ran workshops and panel discussions, and had two invited keynote speakers. The workshops were about communicating science through social media, and also on getting published in one of the Nature journals (similar to the successful workshop ran by SCENARIO here at Reading). The panel discussions were themed around “Science and Development” and “Science in a post-truth world”, looking at ways in which science (particularly that within the NERC remit) can help to solve the UN’s Sustainable Development Goals, and how we communicate science in a time of “fake news”.

IMG_8990

Perhaps my favourite part of the conference were the two keynote speakers. Finding speakers who would appeal to the majority of people attending the conference was no easy task, given the huge range of disciplines!

Opening the conference, Marcus Munafo, Professor in Biological Psychology at Bristol University spoke about the “reproducibility crisis” and how incentive structures affect the scientific process. I can honestly say it was one of the most thought-provoking lectures I’ve ever been to. His main argument was that ultimately science is done by people who have an incentive to do certain things, (e.g. publish in high impact journals), for the benefit of their careers. However, this incentivisation means that often one “big result” can mean more for the career of someone than all the work they’ve done previously, even if that result ended up being retracted or proven false later on, (he went on to demonstrate that happens a lot). One of the statistics he presented was that the higher the impact factor of a journal, the higher the chance of retraction, which I thought was really interesting and certainly made me re-evaluate the way in which I approach my own work.

The other keynote speaker was Lucy Hawkes, Senior Lecturer in Physiological Ecology at Exeter, talking about her work and career, particularly “biologging” of animals and looking at their migratory patterns. Aside from all the great anecdotes and stories (like swimming with sharks in order to plant bio-tags on them), from a meteorologist’s perspective it was interesting listening to her talk about how these migratory patterns change with the climate.

Of course any conference worth its salt has entertainment and things outside work. A BBQ was hosted in the courtyard underneath the Queen’s Tower, and drinks and comedy (the Science Showoff) in the wonderfully titled hBar at Imperial. The Science Showoff in particular was really good, hosted by a professional comedian but with most of the material coming from PhD students at the various institutes (although shamefully no-one from Met volunteered).

IMG_9012

One of the other really useful parts was meeting students from disparate fields at the other institutions. As Joanna Haigh (director of the SSCP DTP) said in her closing speech, the people we meet at these conferences will be our colleagues for our entire careers, so it’s really important to get to know people socially and professionally. In the end I think it went really well, and I’m certainly looking forward to seeing the London students again at next year’s conference!
